Filtered lookup using fetch XML and Javascript-crm2011

Here in my case, I've 3 entity ExamReport(fig2),Course and CourseSubject(fig1). Each Course has many CourseSubjects. In ExamReport record, based on Course it should filtered and show the CourseSubject record which is belonging to select Course record .

// Paste this javascript to ExamReport Entity and call it onChange Event of Course attribute(lookup)

function mylookup1()
{
// enter the scheme name lookup attribute of Course in ExamReport
var advert = Xrm.Page.getAttribute("new_course").getValue();
var aname = advert[0].name;
var aid = advert[0].id;


// this guid is obtained from "online GUID generator"(IE)

    var viewId = "{2fb903e5-1873-41ac-87cd-ba18e08bc5e4}";
// Enter the scheme name of coursesubject
    var entityName = "new_coursesubject";

    var viewDisplayName = "Active Subjects for "+aname;


    var fetchXml =
// Here we need to paste fetch xml code and modify according to this format
// change" into ', Remove <attribute name="createdon" />
// Remove uiname="Java" uitype="new_course" value="{A89857E26-2231-E111-B8D4-000C295BE9F1}"
// in download fetch xml.

 "<fetch version='1.0' output-format='xml-platform' mapping='logical' distinct='false'>"+
"<entity name='new_coursesubject'>"+
"<attribute name='new_coursesubjectid' />"+
"<attribute name='new_subjectname' /> "+
"<order attribute='new_subjectname' descending='false' />"+
"<filter type='and'>"+
"<condition attribute='new_courseid' operator='eq' value='" + aid + "'  />"+
"</filter>"+
"</entity>"+
"</fetch>";

 //build grid layout

    var layoutXml = "<grid name='resultset' " +
                                 "object='1' " +
                                 "jump='new_coursesubjectid' " +
                                 "select='1' " +
                                 "icon='1' " +
                                "preview='1'>" +

                         "<row name='result' " +
                              "id='new_coursesubjectid' >" +

                           "<cell name='new_subjectname' " +
                                 "width='300' />" +
                                 "disableSorting='1' />" +

                         "</row>" +

                       "</grid>";



    //add new view view

    Xrm.Page.getControl("new_subject1").addCustomView(viewId, entityName, viewDisplayName, fetchXml, layoutXml, true);
Xrm.Page.getControl("new_subject2").addCustomView(viewId, entityName, viewDisplayName, fetchXml, layoutXml, true);


}

// fitered lookup based on semester and course (javascript)
function filteredlookupforcoursesubjects()
{
 var advert = Xrm.Page.getAttribute("new_course").getValue();
var aname = advert[0].name;
var aid = advert[0].id;

var sem = Xrm.Page.getAttribute("new_semester").getValue();

//build fetchxml
    var viewId = "{62a56ce8-ed64-4e5b-92c6-6b0b36175dd6}";

    var entityName = "new_coursesubject";

    var viewDisplayName = "Active Subjects for "+aname;


    var fetchXml = "<fetch version='1.0' output-format='xml-platform' mapping='logical' distinct='false'>"+
"<entity name='new_coursesubject'>"+
"<attribute name='new_coursesubjectid' />"+
"<attribute name='new_subjectname' /> "+
"<order attribute='new_subjectname' descending='false' />"+
"<filter type='and'>"+
"<condition attribute='new_courseid' operator='eq'  value='" + aid + "'  />"+
"<condition attribute='new_semester' operator='eq'  value='" + sem + "' />"+
"</filter>"+
"</entity>"+
"</fetch>";

 //build grid layout

    var layoutXml = "<grid name='resultset' " +
                                 "object='1' " +
                                 "jump='new_coursesubjectid' " +
                                 "select='1' " +
                                 "icon='1' " +
                                "preview='1'>" +

                         "<row name='result' " +
                              "id='new_coursesubjectid' >" +

                           "<cell name='new_subjectname' " +
                                 "width='300' />" +
                                 "disableSorting='1' />" +

                         "</row>" +

                       "</grid>";



    //add new view view

    Xrm.Page.getControl("new_subject1").addCustomView(viewId, entityName, viewDisplayName, fetchXml, layoutXml, true);
Xrm.Page.getControl("new_subject2").addCustomView(viewId, entityName, viewDisplayName, fetchXml, layoutXml, true);

}

This is code done by our senior Technical Consultant Palani and Nandan.

Nandan.N
